| | A16.0901 | A16.0901-CCD |
| Optical System | Infinity Color Corrected Optical System |
| Head | Trinocular Head , Gemel Viewing Head, 45 Degree Inclined, Interpupilary Distance 54-75mm, Spliting Ratio 100:0 or 0:100 |
| Eyepiece | PL10x/22mm, High Eyepoint, Wide Field |
| Nosepiece | Revolving Quintuple Nosepiece |
| Objective | LWD Infinity Plan Achromatic Objectives | LWD Infinity Plan Fluorescent Objectives |
| LWDPL10X/0.25, W.D.=7.94mm | LWDPLF4X/0.13, W.D.=18.52mm |
| LWDPL20X/0.40, W.D.=7.66mm | LWDPLF10X/0.30, W.D.=7.11mm |
| LWDPL40X/0.60, W.D.=3.71mm | |
| LWD Infinity Plan Semi-Apochrmatic Objectives |
| | LWDPLFPH20X/0.45, W.D.=5.91mm |
| | LWDPLFPH40X/0.65, W.D.=1.61mm |
| LWD Infinity Plan Phase Contrast Objectives |
| LWDPH20X/0.40, W.D.=7.66mm . | LWDPH10X/0.25, W.D.=7.94mm |
| Working Stage | Fixed Stage Size 250*160mm, Slider Clips | Fixed Stage Size: 250*160mm, Slider Clips |
| / | Extension Plate and Coaxial Moveable Stage, Moving Range120*78mm |
| --Glass Plate | --Glass Plate |
| --Metal Plate | --Metal Plate with Kidney Slot |
| --Petri Dish Holder, Dia.35mm | --Petri Dish Holder, Dia.35mm |
| / | --Slide Holder, Dia.54mm，26.5x76.4mm |
| / | --Teraseki Holder, Dia.65mm，56x81.5mm |
| Focusing | Coaxial Coarse & Fine Focusing System, Coarse Adjustment Range 9mm, Fine Adjustment Precision 0.002mm,with Tension Adjustment, with Safty Stop |
| Condenser | LWD N.A.0.3 Kohler Illumination Condenser, With Phase Contrast Slide Slot, Long Working Distance 72mm. The Whole Set Can Be Rotated Down |
| Phase Contrast | Phase Contrast Plug-board for 10x-40x, Center Adjustable |
| Centering Telescope Dia. 30mm |
| Filter | Dia.45mm Green Interference Filter |
| Dia.45mm Color Temperature Change Filter |
| Attenuation Plate, Transmission 25% |
| Reflected Fluorescence illumination System | With Iris Field Diaphragm, Centering Adjustable |
| --U-LH100HG Mercury Lamp House, Filament Center and Focal Distance Adjustable, with Mirror, Mirror Center and Focal Distance Adjustable |
| --U1-RFLT100 Digital Power Control Box, Wide Voltage Range 90-240V AC |
| --Imported OSRAM 100W DC Mercury Bulb |
| Centered Objective For Mecury Bulb |
| Band-pass Fluorescent Filter B, G | Band-pass Fluorescent Filter B, G, UV |
| 30ND25 Attenuation Plate |
| CCD Adapter | 0.67x CCD Adapter, for 2/3"CCD Camera |
| CCD Camera | / | 1.4M, 2/3"CCD, USB 2.0 Scientific Research Class Cold CCD Digital Camera |
| Light | Critical Illumination, With Iris Aperture, Halogen 6V30W, Pre-centered, Intensity Adjustable |
| Power | Wide Voltage 90-240V |
