A11.1508-02 Student Biological Microscope, Vertical Monocular Head

  • Monocular Vertical Head, Whole Body Inclination Adjustable
  • Total Magnification 40x~1600x Available
  • Coarse & Fine Focusing Knob, Focusing Range 50mm
  • Single Layer Stage With Vernial Scale Attached
  • Plan-Concave Mirror Dia. 40mm

Products Details

A11.1508 Student Biological Microscope 1 2 3 4 5 6
Head Mono Vertical Tube ● ● ● ● ● ●
Eyepiece 5x - - ● ● ● ●
10x ● ● ● ● ● ●
12.5x ● - - ● - -
15x - - - - ●
16x   ● - -   ●
Objective 4x ● ● - - - -
10x ● ● ● ● ● ●
40x ● ● ● ● ● ●
100x - - ● ● ● ●
Nosepiece Triple Revolving Nosepiece ● ● ● ● ● ●
Stage Stage with Specimen Clips, Size110x120mm ● ● - - - -
Stage with Specimen Clips, Size120x120mm - - ● ● ● ●
Mechanical Slide Holder Vernial Scale - - ● ● ● ●
Condenser 5 Holes Disc Diaphragm ● ● - - - -
N.A.=1.25 with Iris Diaphragm & Filter - - ● ● ● ●
Focusing Separate Coarse and Fine Focusing Knobs ● ● ● ● ● ●
Coarse Fousing Range:50mm,
Fine Adjustment Range :1.8mm-2.2mm
Light Source Concave-Plan Mirror, Dia 50mm ● ● ● ● ● ●
Optional Accessories
Light Source Attachable Electrical Illuminator (110V/220V 20W) A56.1501
