A23.3645N-R1 Zoom Stereo Microscope, Mobile Phone Repair

  • 9" HD LCD Screen + Digital Camera, Viewing Angel Freely Adjustable
  • 0.7~4.5x High Quality Optical System Zoom Stereo Microscope
  • Trinocular Head Light Split 5:5 Support View Image In Eyepiece & LCD At Same Time
  • Upper 56 LEDs Right Light Brightness Adjustable
  • Professional Soft Pad Working Area For Mobile Phone Repair On Stand


Products Details

A23.3645N-R1 Series
DIY Phone PCB Repair MicroscopeA23.3645N- R1A23.3645N- R1L1A23.3645N- R1H1HeadTrinocular Head, With Eyepiece Adapter  LCD Screen 9" With Digital Camera, AV Output  HDMI+USB Digital Camera 38.0M Pixels  45° Inclined, 360°Rotatable, Both Tube ±5 Diopter Adjustable, Interpupillary Adjustment 54-75mmEyepieceWF10x/20mm, Both With Eye-cupZoom Lens0.7~4.5xZoom Ratio1:6.5Magnification7x-45x, Up To 3.5x-180x With Optional Eyepieces And Auxiliary LensW.D.Working Distance100mm, With Standard 1x LensF.O.VField Of View 1~95.2mmStandPole Stand, Size 200*255*22mm, Pole Height 240mm, Dia.32mm, With Heat Resist Soft Rubber Pad, Working Area For Phone PCB RepairLight SourceUpper 56 LEDs Right Light Brightness AdjustableOptional AccessoriesCata.No.EyepieceWF15x/15mm, High-eyepointA51.3621-1515WF20x/10mm, High-eyepointA51.3621-2010WF25x/9mm, High-eyepointA51.3621-2509WF30x/8mm, High-eyepoint
A23.3645N-R2 Series DIY Phone PCB Repair Microscope A23.3645N- R2 A23.3645N- R2L1 A23.3645N- R2H1
Head Trinocular Head, With Eyepiece Adapter
LCD Screen 9" With Digital Camera, AV Output
HDMI+USB Digital Camera 38.0M Pixels
45° Inclined, 360°Rotatable, Both Tube ±5 Diopter Adjustable, Interpupillary Adjustment 54-75mm
Eyepiece WF10x/20mm, Both With Eye-cup
Zoom Lens 0.7~4.5x
Zoom Ratio 1:6.5
Magnification 7x-45x, Up To 3.5x-180x With Optional Eyepieces And Auxiliary Lens
W.D. Working Distance100mm, With Standard 1x Lens
F.O.V Field Of View 1~95.2mm
Stand Large Pole Stand, Size 200*255*8mm, Pole Height 240mm, Dia.32mm, With Heat Resist Soft Rubber Pad, Working Area For Phone PCB Repair
Light Source Upper 56 LEDs Right Light Brightness Adjustable
Optional Accessories Cata.No.
Eyepiece WF15x/15mm, High-eyepoint A51.3621-1515
WF20x/10mm, High-eyepoint A51.3621-2010
WF25x/9mm, High-eyepoint A51.3621-2509
WF30x/8mm, High-eyepoint A51.3621-3008
Auxiliary Lens 0.5X,W.D. 165mm A52.3621-0.5x
1.5X,W.D. 45mm A52.3621-1.5x
2.0X,W.D. 30mm A52.3621-2.0x
ly: Arial;">A51.3621-3008Auxiliary Lens0.5X,W.D. 165mmA52.3621-0.5x1.5X,W.D. 45mmA52.3621-1.5x2.0X,W.D. 30mmA52.3621-2.0x
